Manitou MLT 635-130 PS+
Call for Price
Specifications
capacities
weight and dimensions
performances
engine
transmission
hydraulics
tank capacities
noise and vibration
miscellaneous
technical sheet
Documents
Model
MLT
Category Name
Equipment
Year
2025
Sale Type
New
Manufacturer
Manitou
Max. Capacity
3500 kg
Max. Outreach
3.20 m
Max. Lifting Height
6.08 m
Reach At Max. Height
0.60 m
Breakout Force With Bucket
5402 daN
Wheelbase
2.60 m
Overall Width
2.39 m
Tilt-up Angle
12 °
Front Overhang
1.11 m
Overall Height
2.38 m
Standard Tires
Alliance - A580 - 460/70 R24 159A8
Tilt-down Angle
134 °
Ground Clearance
0.41 m
Overall Cab Width
0.95 m
Drive Wheels (front / Rear)
2 / 2
Unladen Weight (with Forks)
7606 kg
Steering Wheels (front / Rear)
2 / 2
External Turning Radius (over Tyres)
3.77 m
Overall Length To Carriage (with Hitch)
4.50 m
Dump
2.20 s
Crowd
2.50 s
Lifting
5.80 s
Lowering
4.50 s
Extension
3.70 s
Retraction
3.80 s
Engine Norm
Stage V
Engine Brand
Deutz
Engine Model
TCD 3.6 L4
Reversible Fan
Standard
Drawbar Pull (Laden)
8500 daN
Engine Cooling System
4 radiators (water + intercooler + hydraulic oil + transmission oil)
Max. Torque / Engine Rotation
500 Nm @1600 rpm
I.C. Engine Power Rating / Power (kW)
129 Hp / 95 kW
Number Of Cylinders / Capacity Of Cylinders
4 - 3621 cm³
Parking Brake
Automatic negative parking brake
Service Brake
Oil-immersed multi-discs braking on front & rear axles
Differential Lock
Limited slip differential on front axle
Transmission Type
Torque converter
Number Of Gears (forward / Reverse)
6 / 3
Max. Travel Speed (may Vary According To Applicable Regulations)
40 km/h
Hydraulic Pump Type
Variable displacement pump
Flow Sharing Distributor
Standard
Hydraulic Flow / Pressure
150 l/min - 270 bar
Fuel Tank
120 l
Hydraulic Oil
135 l
Diesel Exhaust Fluid (AdBlue® Type)
10 l
Vibration On Hands/arms
< 2.50 m/s²
Noise To Environment (LwA)
105 dB
Noise At Driving Position (LpA) Tested Following NF EN 12053 Norm
72 dB
Controls
JSM
Tractor Homologation
Tractor homologation
Safety Cab Homologation
Cabin ROPS - FOPS level 2
Technical Sheet
