Manitou MRT 2660 e

Listing image Listing image Listing image Listing image
Specifications

Model MRT Category Name Equipment Year 2025
Sale Type New Manufacturer Manitou Price Contact for price CAD
Description

100% electric. MRT 2660 e is truly a versatile tool for your handling operations with zero emission, low noise level and fuel reduced consumption.

6 000 kg max capacity, 22m of lifting height. Lithium-ion battery, ensure : low maintenance, possibility of opportunity charge (partial and frequent recharging of the battery) and long lifespan.

Modular project : possibility to add a 2nd battery to gain autonomy or a range extender (heat engine that recharges the battery) in hybrid mode. All the advantages of the MRT Vision + (visibility, performance, comfort) in 100% electric.

CAPACITIES
Max._capacity
6000 kg
Max._outreach
21.70 m
Max._lifting_height
25.90 m
WEIGHT AND DIMENSIONS
Wheelbase
3.05 m
Overall_width
2.50 m
Tilt-up_angle
12 °
Overall_height
3.10 m
Overall_weight
18000 kg
Tilt-down_angle
110 °
Turret_rotation
360 °
Ground_clearance
0.38 m
Overall_cab_width
0.96 m
Length_to_face_of_forks
8.08 m
Overall_length_(with_forks)
9.28 m
Forks_length_/_width_/_section
100 mm x 1200 mm x 60 mm
WHEELS
Steering_mode
2 wheel steer, 4 wheel steer, Crab mode
Standard_tyres
445/65 R22,5
Drive_wheels_(front_/_rear)
2 / 2
STABILISERS
Stabs_Type
Telescopic Duplex
Controls_with_stabs
Stabs Commands Individual or Simultaneous
ENGINE/BATTERY
Battery_energy
65 kWh
Battery_capacity
105 Ah
Battery_technology
Lithium-ion
Battery_max._voltage
680 V
Hydraulic_motor_power
84 kW
Battery_nominal_voltage
624 V
Electric_engine_power_rating
107 kW
Charger_Power_/_Phase_/_Current_type
11 kW / Single-phase or three-phase / AC
TRANSMISSION
Drawbar_pull
8600 daN
Parking_brake
Automatic negative parking brake
Service_brake
Oil-immersed multi-discs braking on front & rear axles
Max._travel_speed
37 km/h
Transmission_type
Electrical
Drawbar_pull_continuous
4300 daN
Number_of_gears_(forward_/_reverse)
2 / 2
PERFORMANCES
Max_Gradeability_(laden_/_unladen)
36 % / 48 %
Gradeability_continuous_(laden_/_unladen)
18 % / 23 %
HYDRAULICS
Hydraulic_flow
175 l/min
Hydraulic_Pressure
350 bar
Hydraulic_pump_type
Fixed displacement piston
Hydraulic_tank_capacity
200 l
NOISE AND VIBRATION
Vibration_on_hands/arms
< 2.50 m/s²
Noise_to_environment_(LwA)
103 dB
Noise_at_driving_position_(LpA)
65 dB
MISCELLANEOUS
Controls
2 Joysticks
Safety_cab_homologation
Cabin ROPS - FOPS level 2
Steering_wheels_(front_/_rear)
2 / 2
Attachment_recognition_system_(E-Reco)
Standard
TECHNICAL SHEET
Name Link
Technical sheet Download
