Sunflower 6221 LAND FINISHERS

Videos
Call for Price
Overview

WORKING WIDTHS FROM 17’ 4” TO 20’ 4”



Perform your discing, incorporation, cultivating, and field finishing in one tillage pass. Don't accept poor germination when the solution is seed bed preparation. The Sunflower 6221 Land Finisher can enhance seed-to-soil contact and create a favorable environment for early root growth. The 6221 is designed for smaller tractors but delivers large performance.

Specifications
Model
6221
Year
2022
Sale Type
New
Manufacturer
Sunflower
specs

Model Working width ft (m) Transport width ft (m) Transport height ft (m) Weight lbs (kg) Power requirements
6221-17 17’-4” (5.3) 17’-5” (5.3) 11’-6” (3.5) 8,772 (3,979) 8 to 10 hp/ft
6221-20 20’-4” (6.2) 21’ (6.4) 13’-1” (4.0) 9,315 (4,225) 8 to 10 hp/ft



features

6221 LAND FINISHER FEATURES



  • Loaded with features to help comply with today's residue management requirements

  • Self centering hitch, moves the land finisher over so the unit is centered behind the tractor during transport

  • Folds Hydraulically to a narrow width of 13' 6" or 15' 4" for a safe transport between fields

  • Single point depth control prevents the need to climb on the frames to set the hydraulic cylinders for a depth adjustment

  • The unique disc gang reel is located directly behind the disc gang and provides four important actions:
    1. Pulverizes soils and clods
    2. Thoroughly incorporates chemicals
    3. Vigorously mixes soil and residue
    4. Prevents lateral movement of the soil. Eliminates ridging.

  • Disc gangs features 20" diameter conservation blades with 1 5/16" concavity

  • Disc blades spaced at 7 1/2" and are preset to an 8 degree cutting angle

  • Disc gangs features self aligning flangette bearing that are triple sealed and greaseable

  • 1 3/4" diameter gang shafts and steel spools ensure precise alignment of the entire disc gang

  • Spring Tension or 2-piece "S" tine shanks

  • Disc gangs can be adjusted from 1" below the sweeps to 5" above

  • 17' and 20' working widths

  • A transport safety light kit and SMV emblem are standard on all Sunflower equipment

view land finisher features

Callout Image

Unique Disc Gang Reel



The unique disc gang reel is located directly behind the disc gang and provides four important actions:

  • Pulverizes soils and clods
  • Thoroughly incorporates chemicals
  • Vigorously mixes soil and residue
  • Prevents lateral movement of the soil and eliminates ridging



Callout Image

Heavy-Duty Disc Gang Assemblies



  • 1 3/4-inch-diameter industrial-size gang shafts

  • 20-inch, 1.32-inch low concavity disc blades either six gauge or four gauge

  • 7 1/2-inch disc gang spacing with steel spools

  • Triple-sealed self-aligning flangette disc gang bearings





Callout Image Disc Gang Placement



The disc gang placement directs soil into the gang reels. The gang reels located immediately behind the disc gangs level the surface profile by preventing the lateral movement of soil that would create ridges and valleys.



Callout Image

Spring-Cushioned Disc Gangs



The disc gangs are equipped with heavy-duty spring-cushioned mounts to protect them from obstructions such as rocks and stumps. These mounts allow the gangs to penetrate more uniformly and prevent gouging when crossing ditches or terraces.



Callout Image Spring-Cushion Shanks



With 25 inches of under-frame clearance, the 5/8-inch-thick, 190 lb. point-load shanks on a five-bar cultivator placement provide optimum trash flow.

Callout Image

Adjustable Disc Gang Depth



The gangs are adjustable from 1 inch below to 5 inches above the cultivator sweeps. Adjustment is accomplished with either the manual or hydraulically adjustable feature.

Sunflower 6221 LAND FINISHERS

S-TINE SHANKS



S-tine 160 lb. point-load shanks are also available if rocks and stones are not present and the heavier spring-tension shanks are not necessary.

Available on all series models.
